Fanvil Smart Voip C600 Andriod Phone
Manufacturer: Fanvil Smart Voip
Call for pricing

Main Features

Specification

Download

Main FeaturesTo the top
 Call Forwarding
 Call Transfer(blind/attended/alert)
 Call Holding
 Call Waiting
 Call Conference
 BLF List
 Capable of 10 way conversation
 Join Call
 Pickup
 Call Completion
 Hot desk function
 Soft DSS Key (Upto 100)
 Auto Redial / un-redial
 Support multi line and pre-dial
 Support messaging and MWI
 Voice recording during talking /local
 Flexible dial plan
 Hotline/Warm-line
 Call Rejection
 Black List
 Barring function for outgoing calls
 Do Not Disturb
 Auto Answer (Hands- free / Headset)
 Caller ID display
 CLIR (rejects anonymous calls)
 CLIP (to make an anonymous call)
 Dial without registration
 Supports Call Logs with Missed / Incoming /
    Outgoing calls
 Intercom/Intercom barge
 Password dial
 Headset ring
 Direct IP call without SIP proxy


SpecificationTo the top
Display
 7” TFT 800x480 Capacitive Multi Touch Screen

Call Features
 Call Forwarding
 Call Transfer (blind/attended/alert)
 Call Holding
 Call Waiting
 Call Conference
 BLF List
 Capable of 10 way conversation
 Join Call
 Pickup
 Call Completion
 Hot desk function
 Soft DSS Key (Upto 100)
 Auto Redial / un-redial
 Support multi line and pre-dial
 Support messaging and MWI
 Voice recording during talking /local
 Flexible dial plan
 Hotline/Warm-line
 Call Rejection
 Black List
 Barring function for outgoing calls
 Do Not Disturb
 Auto Answer (Hands- free / Headset)
 Caller ID display
 CLIR (rejects anonymous calls)
 CLIP (to make an anonymous call)
 Dial without registration
 Supports Call Logs with Missed / Incoming /
    Outgoing calls
 Intercom/Intercom barge
 Password dial
 Headset ring
 Direct IP call without SIP proxy

Phone features
 Android 4.2 OS
 Supports high quality video call
 Supports SIP 2.0 (RFC3261) and correlative
    RFCs
 Supports 6 SIP servers and Backup SIP proxy
    servers.
 Supports SIP UDP/TCP/TLS
 Supports HDMI
 Supports USB Host
 Supports Acoustic echo cancellation (AEC) -
    128ms max filter length in duplex speaker
    phone mode
 Supports PLC & adaptive jitter buffer

Audio Features
 Wideband codec: G.722
 Narrowband codec: G.711(A/µ), G.723.1,
    G.729AB, iLBC, AMR
 DTMF: In-band, Out-of-band(RFC 2833) and
    SIP INFO
 Full-duplex hands-free speaker phone with
    AEC (Max filter length – 128ms)
 Voice Activity Detection (VAD)
 Comfort Noise Generation (CNG)
 Adaptive jitter buffer
 Packet loss concealment (PLC)
 Audio format: WAV/MP3/OGG

Video Features
 Video codec: H.264 / H.263
 Image codec: JPEG/PNG/BMP/GIF
 Video format: MP4/3GP/FLV
 Video call resolution: QCIF / CIF / VGA / 4CIF
     (1280x720P Optional)
 Bandwidth selection: 64kbps~4Mbps
 Frame rate selection: 10~30fps
 Picture-in-Picture (PIP)
 Video from remote site can be displayed in
    full screen
 Supports up to 4 video display mode

Network/ Security Features
 WAN/LAN: support bridge mode
 Supports PoE (802.3af)
 Supports main DNS and secondary DNS server
 Supports VLAN
 Supports SNTP Client
 Supports VPN L2TP / PPTP / IPSec
 Supports SIP SRTP,
 Supports Web HTTP / HTTPS
 Supports QoS: 802.1p/q, DSCP
 Supports MD5 authentication
 Supports Web Filter
 DHCP/ static/ PPPoE
 STUN

Maintenance & Management
 Android 4.2
 Supports third party communication APP
 Supports Web, Telnet
 Web Management with different account right
 Supports automatic upgrades/
    configuration deployment
 Supports encrypted configuration files
    download with AES
 Supports pushing message
 Supports Auto-Provisioning (DHCP option/
    PnP/ Phone flash)
 Supports TR-069
 Supports Web upgrade
 Supports U Disk/SD upgrade
 Supports backup/restore/factory reset data

Physical Features
 Adapter Input:100-240V
 Adapter Output:12V/1A
 WAN Port -10/100/1000 Base-T RJ-45 for LAN
 LAN Port- 10/100/1000 Base-T RJ-45 for PC
 HDMI Port - Type A
 SD Interface - TF Card Support Upto 32G
 USB Port- USB 2.0
 Power Consumption- Idle: 2.5W/Active: 5W
 LCD Size Diagonal:7 inch (800 x 480)
    Capacitive touch screen
 Camera- Adjustable Position
 Operation Temperature: 0~40?
 Relative Humidity: 10~65%
 CPU Freescale Core Quad 1 Ghz
 SDRAM - 1GB DDR3 1066
 Flash- 4GB
 Weight- Phone:1.2Kg/Total:1.8Kg
