| Mechanical |
|---|
| Dimensions | 110 x 110 x 250 mm (4.3 x 4.3 x 9.8") |
| Weight | 1.2 kg (2.7 lb) |
| Enclosure material | Polycarbonate |
| Hardware |
|---|
| Processor | Quad-Core ARM® Cortex® A53s at 2.2 GHz |
| Memory | 1GB DDR3L |
| Management interface | WiFi
Ethernet |
| Networking interface | (1) GbE RJ45 WAN
(4) GbE RJ45 LAN |
| Power method | Universal AC input, 100-240V AC, 1A Max., 50/60 Hz |
| Max. power consumption | 35W |
| ESD/EMP protection | Air/contact: ± 24kV |
Max. TX power
US:
2.4 GHz
5 GHz
International:
2.4 GHz
5 GHz |
23 dBm
19 dBm (low band)/ 20 dBm (high band)
23 dBm*
20 dBm**
*Depends from the country selected, up to 30 dBm per chain.
**Depends from the country selected, up to 24 dBm per chain. |
MIMO
US:
2.4 GHz
5 GHz
International:
2.4 GHz
5 GHz |
4 x 4
4 x 4 (low band) / 8 x 8 (high band)
4 x 4
8 x 8 |
Speeds
US:
2.4 GHz
5 GHz
International:
2.4 GHz
5 GHz |
1150 Mbps
1700 Mbps(low band) / 4800 Mbps (high band)
1148 Mbps
4800 Mbps |
Antenna gain
2.4 GHz
5 GHz |
3 dBi
6 dBi |
| Antenna | Internal dual-band metal stamp with 12 polarity |
| Haptics | Yes |
| Display | 4.7" diagonal, 274 x 1268, 279 ppi, G+F touch, full color |
| LED | Green ring |
| Button | Factory reset |
| Ambient operating temperature | -10 to 45° C (14 to 113° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Software |
|---|
| WiFi standards | Up to WiFi 6 |
| WiFi functions | MU-MIMO, OFDMA, TX-beamforming |
| Wireless security | WPA2 |
| VLAN | Yes |
| Advanced QoS | Yes |
| Guest traffic isolation | Yes |
| Power save | Yes |
| Supported data rates | 802.11a: 54 Mbps
802.11b: 11 Mbps
802.11g: 54 Mbps
802.11n: 600 Mbps + 600 Mbps
802.11ac: 1733 Mbps + 800 Mbps
802.11ax: 4800 Mpbs Router-Mesh connection (Backbone)
802.11ax: 4800 Mbps + 1148 Mbps (Available to clients) |
Operating frequency*
2.4 GHz
5 GHz |
2412 - 2472 MHz
5150 - 5875 MHz
* Depends on regulatory region. |
