BR1200G-JP | APC

APC Power-Saving RS 1200 100V
Manufacturer: APC
Call for pricing
Model NameAPC Power-Saving RS 1200 100V
IncludesCD with software,Telephone Cable,USB cable,User Manual
Standard Lead TimeUsually in Stock
Product DistributionJapan
Output Power Capacity720 Watts / 1200 VA
Max Configurable Power (Watts)720 Watts / 1200 VA
Nominal Output Voltage100V
Output Frequency (sync to mains)50 Hz,60 Hz
nullLine Interactive
Waveform TypeSquare wave
Output Connections(5) NEMA 5-15R (Battery Backup),(5) NEMA 5-15R (Surge Protection)
Nominal Input Voltage100V
Input Frequency50/60 Hz +/- 3 Hz (auto sensing)
Input ConnectionsNEMA 5-15P
Cord Length1.83 meters
Input voltage range for main operations83 - 122
Batteries & Runtime
Battery TypeMaintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time16
Replacement BatteryAPCRBC109
RBC™ Quantity1
Communications & Management
Interface Port(s)Optional Simple Signalling RS232 cable,USB
Control panelMulti-function LCD status and control console
Audible AlarmAlarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rating880
Data Line ProtectionAnalog phone line for phone/fax/modem/DSL (RJ-11 connector),Coaxial cable for CATV/SATV/modem/Audio-Video (coax connector)
Maximum Height301 mm
Maximum Width112 mm
Maximum Depth382 mm
Net Weight11.45 kg
Shipping Weight12.63 kg
Shipping Height387 mm
Shipping Width238 mm
Shipping Depth488 mm
Master Carton Units1.0
Units per Pallet24.0
# of Layers per Pallet4
# of Units per Layer per Pallet8
Operating Environment0 - 40 °C
Operating Relative Humidity0 - 95
Operating Elevation0-9000 meters
Storage Temperature-5 - 45 °C
Storage Relative Humidity0 - 95
Storage Elevation0-4500 meters
Audible noise at 1 meter from surface of unit45.000
Regulatory ApprovalsTUV,VCCI Class B
Standard Warranty2 years repair or replace
Sustainable Offer Status
