Rocket M5 AC | Airmax | UBNT(Ubiquiti)

Rocket M5 AC supports high data rates, which require dense modulation: 256QAM – a significant increase from 64QAM, which is used in airMAX
Manufacturer: Ubiquiti Networks
Call for pricing

Performance Breakthrough

airMAX® ac products offer improved latency, noise immunity, scalability and significantly increased throughput performance.

Superior Processing

Ubiquiti's airMAX® engine with custom IC dramatically improves TDMA latency and network scalability. The custom silicon provides hardware acceleration capabilities to the airMAX scheduler, to support the high data rates and dense modulation used in airMAX ac technology.

Plug and Play Integration

The innovative airMAX® ac antennas feature significant advances in beam and energy isolation performance for increased capacity of airMAX networks.

Advanced Software Technology

Ubiquiti’s airMAX® technology is proven in millions of deployments worldwide, exhibiting outstanding performance in outdoor environments. The TDMA airMAX protocol enables unprecedented scalability, high throughput and low latency in unlicensed, multipoint networks.

Model Comparison

FrequencyFull-Band 5 GHzMid-Band 5 GHzMid-Band 5 GHz
Throughput500+ Mbps (Max. 80 MHz)500+ Mbps (Max. 80 MHz)330+ Mbps (Max. 40 MHz)
Ports(1) 10/100/1000 Ethernet(1) 10/100/1000 Ethernet(1) 10/100/1000 Ethernet
Link TypePtP, PtMP*PtP, PtMP*PtMP, PtP*
airPrism™ TechnologyNoYesYes
* Requires firmware airOS® v7.1.1 or higher.
