U6 Lite | U6-Lite

Compact, ceiling-mounted WiFi 6 AP with 4 spatial streams ideal for smaller offices.
Manufacturer: Ubiquiti Networks
Call for pricing
    Overview
    Dimensions
    Ø160 x 33 mm (Ø6.3 x 1.3")
    WiFi Standard
    WiFi 6
    Spatial Streams
    4
    Coverage Area
    115 m² (1,250 ft²)
    Max. Client Count
    300+
    Uplink
    GbE
    Mounting Locations
    Ceiling, wall
    Mounting Plate
    Pro mounting plate (Included)
    Power Method
    PoE
    Performance
    MIMO
    5 GHz
    2 x 2 (DL/UL MU-MIMO)
    2.4 GHz
    2 x 2 (SU-MIMO)
    Max. Data Rate
    5 GHz
    1.2 Gbps (BW80)
    2.4 GHz
    300 Mbps (BW40)
    Antenna Gain
    5 GHz
    3 dBi
    2.4 GHz
    2.8 dBi
    Max. TX Power
    5 GHz
    23 dBm
    2.4 GHz
    23 dBm
    Max. BSSIDs
    8 per Radio
    Supported Data Rates
    802.11ax (WiFi 6)
    7.3 Mbps to 1.2 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80)
    802.11ac (WiFi 5)
    6.5 Mbps to 866.7 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
    802.11n
    6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
    Features
    Wireless Meshing
    Yes
    Band Steering
    Yes
    802.11v BSS Transition Management
    Yes
    802.11r Fast Roaming
    Yes
    802.11k Radio Resource Management (RRM)
    Yes
    Advanced Radio Management
    Yes
    Passpoint (Hotspot 2.0)
    Yes
    Captive Hotspot Portal
    Custom Branding Landing Page
    Yes
    Voucher Authentication
    Yes
    Payment-Based Authentication
    Yes
    External Portal Server Support
    Yes
    Password Authentication
    Yes
    Guest Network Isolation
    Yes
    Private Pre-Shared Key (PPSK)
    Yes
    WiFi Speed Limiting
    Yes
    Client Device Isolation
    Yes
    WiFi Schedules
    Yes
    RADIUS over TLS (RadSec)
    Yes
    Dynamic RADIUS-assigned VLAN
    Yes
    Hardware
    Max. Power Consumption
    12W
    Supported Voltage Range
    44—57V DC
    Networking Interface
    (1) GbE RJ45 port
    Weight
    Device: 300 g (10.6 oz)With mount: 315 g (11.1 oz)
    Management
    EthernetBluetooth
    Enclosure Material
    Polycarbonate, aluminum
    Mount Material
    Polycarbonate, SGCC steel
    LEDs
    System
    White/Blue
    Channel Bandwidth
    HT 20/40, VHT 20/40/80, HE 20/40/80 (MHz)
    Certifications
    CE, FCC, IC
    Operating Frequency
    US/CA:2400 - 2472 MHzU-NII-1: 5150 - 5250 MHzU-NII-2A: 5250 - 5350 MHzU-NII-2C: 5470 - 5725 MHzU-NII-3: 5725 - 5850 MHzWorldwide:2400 - 2483.5 MHz5150 - 5725 MHz
    Ambient Operating Temperature
    -30 to 60° C (-22 to 140° F)
    Ambient Operating Humidity
    5 to 95% noncondensing
