Dreams Network | u7-pro-max-u7-pro-max

Ceiling-mounted WiFi 7 AP with 8 spatial streams, 6 GHz support, and a dedicated spectral scanning engine for interference-free WiFi in demanding, large-scale environments.

Manufacturer: Ubiquiti Networks

Be the first to review this product

Call for pricing

Quantity:

Description

Dimensions

Ø206 x 46 mm(Ø8.1 x 1.8")

WiFi Standard

WiFi 7

Spatial Streams

Coverage Area

160 m² (1,750 ft²)

Max. Client Count

500+

Uplink

2.5 GbE

Mounting

Ceiling, Wall(Pro Mount Included)

Power Method

PoE+

MIMO

6 GHz

2 x 2 (DL/UL MU-MIMO)

5 GHz

4 x 4 (DL/UL MU-MIMO)

2.4 GHz

2 x 2 (DL/UL MU-MIMO)

Max. Data Rate

6 GHz

5.8 Gbps (BW320)

5 GHz

8.6 Gbps (BW240)

2.4 GHz

688 Mbps (BW40)

Antenna Gain

6 GHz

5.9 dBi

5 GHz

6 dBi

2.4 GHz

4 dBi

Max. TX Power

6 GHz

23 dBm

5 GHz

29 dBm

2.4 GHz

23 dBm

Max. BSSIDs

8 per Radio

Supported Data Rates

802.11be (WiFi 7)

6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320)5 GHz: 7.3 Mbps to 8.6 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240)

802.11ax (WiFi 6/6E)

7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)

802.11ac (WiFi 5)

6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)

802.11n

6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)

Wireless Meshing

Band Steering

802.11v BSS Transition Management

802.11r Fast Roaming

802.11k Radio Resource Management (RRM)

Advanced Radio Management

Real-Time Spectral Analysis

Passpoint (Hotspot 2.0)

Captive Hotspot Portal

Custom Branding Landing Page

Voucher Authentication

Payment-Based Authentication

External Portal Server Support

Password Authentication

Guest Network Isolation

Private Pre-Shared Key (PPSK)

WiFi Speed Limiting

Client Device Isolation

WiFi Schedules

RADIUS over TLS (RadSec)

Dynamic RADIUS-assigned VLAN

Max. Power Consumption

25W

Supported Voltage Range

44—57V DC

Networking Interface

(1) 1/2.5 GbE RJ45 port

Weight

680 g (1.5 lb)

Management

Ethernet

Enclosure Material

Polycarbonate, aluminum

Mount Material

Stainless steel (SUS304), galvanized steel (SGCC)

LEDs

System

White/Blue

Channel Bandwidth

HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)

NDAA Compliant

Certifications

CE, FCC, IC

Operating Frequency

US/CA:2400 - 2472 MHzU-NII-1: 5150 - 5250 MHzU-NII-2A: 5250 - 5350 MHzU-NII-2C: 5470 - 5725 MHzU-NII-3: 5725 - 5850 MHzU-NII-5 to U-NII-8 : 5925 - 7125 MHzWorldwide:2400 - 2483.5 MHz5150 - 5725 MHz5925 - 7125 MHz

Ambient Operating Temperature

-30 to 50° C (-22 to 122° F)

Ambient Operating Humidity

5 to 95% noncondensing

Application Requirements

UniFi Network

Version 8.2.93 and later
