TPA-PAF

TwistPort Adaptor adapts 3rd party radios to RF elements proprietary TwistPortTM waveguide connector. Integration of the radio is smooth and requires no tools. Making 3rd party radios compatible with TwistPortTM allows for using the radio with any TwistPortTM antenna ever made and enable superior performance, noise immunity and network scalability.

tpa-paf-over

This TP-A is also compatible with the newest Gen 2 of Rocket Prism 5AC, AF-5XHD airFiber radios and LTU Rocket. Complete List of compatible radios includes: UBNT Rocket Prism 5AC, Rocket Prism 5AC Gen2, airFiber 5X and airFiber 5XHD, LTU Rocket.

The migration path from Rocket Prism 5AC to airFiber 5X platform is smooth and effective, as no additional investment on TP-A is required.

TP-A PAF contains well protected space for GPS antenna that comes with UBNT radios. After integration, GPS antenna and antenna cable are covered and well protected. No more issues with antenna attachment or with troubleshooting damaged GPS antennas.

Product ID: TPA-PAF

Antenna Connection: TwistPort^TM - Quick Locking Waveguide Port

Radio Connection: 2x Slide-On RP-SMA and 1x SMA for GPS

Materials: Insert - Aluminium Alloy, Adaptor - UV stabilized and weather resistant ABS plastic

Flame Rating: UL 94 HB

Temperature: -40°C to +60°C (-40°F to +140°F)

Wind Survival: 160 km/h

Frequency Range: 5180 - 6400 MHz

Polarization: Dual Linear H + V

Antenna Compatibility: Any TwistPort^TM Compatible Antenna

Radio Compatibility: Ubiquiti^TM: Rocket^® Prism 5AC, Rocket^® Prism 5AC Gen2, airFiber^® 5X, airFiber^® 5X-HD, LTU Rocket

TPA-PAF replaces the folowing EOL products: TwistPort Adapter for Rocket AC Prism TP-ADAP-R5AC-PRISM; TwistPort Shielded Adapter v2 for Rocket AC Lite TP-ADAPTOR-R5AC-S-V2.
