VoIP GSM Gateway TG100 | Yeastar

Yeastar TG100 is a fully featured 1 port VoIP GSM/CDMA/UMTS gateway that provides GSM/CDMA/UMTS network connectivity for softswitch and IP PBX.
Manufacturer: Yeastar
Call for pricing
tg100 features
tg100 reduce costs for soho

Reduce Costs for SOHO

  • Rich functionalities
    A robust feature set that fulfills your various needs and cuts communication cost
  • Easy management
    Simple and intuitive Web-based configuration saves you loads of time
  • Reliable performance
    Stable with advanced hardware and software architecture
  • Excellent interoperability
    Interoperable with a broad list of softswitch, PBX, and IP-PBX like Elastix and Lync Server

Mobile1 GSM/CDMA/UMTS Channel
GSM Frequency850/900/1800/1900 MHz
UMTS Frequency850/1900 MHz, 850/2100 MHz, 900/2100 MHz
CDMA Frequency800 MHz
Antenna Splitter (4 in 1)
ProtocolSIP, IAX2
TransportUDP, TCP, TLS, SRTP
Voice CodecG.711 (alaw/ulaw), G.722, G.726, G.729A, GSM, ADPCM, Speex
Echo CancellationITU-T G.168 LEC
DTMF ModeRFC2833, SIP INFO, In-band
Console Port
Calling TypeTermination (VoIP to GSM/CDMA/UMTS), Origination (GSM/CDMA/UMTS to VoIP)
LAN1 10/100Mbps
Network ProtocolFTP, TFTP, HTTP, SSH
NAT TraversalStatic NAT, STUN
NetworkDHCP, DDNS, Firewall, OpenVPN, Static IP, QoS, Static Route, VLAN
Dimensions (L × W × H) (mm)110 x 70 x 24
Power SupplyDC 12V, 1A
Operation Range0°C to 40°C, 32°F to 104°F
Storage Range-20°C to 65°C, -4°F to 149°F
Humidity10-90% non-condensing
